FORGED GLOBE VALVE
Technical Data:
Manufacturing Std | BS 5352 |
---|---|
Flange to Flange Distance | ANSI B 16.10 |
Ansi Class / Rating | 800#, 1500# , 2500# |
End Connection | Screwed Ends to BSP/BSPT/NPT, Socket Weld Ends to ANSI B16.11 |
Inspection and Testing Std | API 598 / BS 6755 |
Category : | Uncategorized |
Description
Abcovalves Forged Steel Globe Valve screwed and flanged ends are Bolted Bonnet, outside screw and yoke type, rising spindle & non rising hand wheel construction, in size 1/2” (DN15) to 2” (DN50) to suit various critical, non-critical applications and pressure rating in 800 and 1500 class in Regular (Reduced) Port. Our
Abcovalves manufacture Forged Steel threaded in wide range of Body Materials like ASTM A 105 – Forged Carbon Steel, ASTM A 182 F 304 / 304 L / 316 / 316 L, Forged Stainless Steel 304 / 304 L / 316 / 316 L, ASTM A 182 F 11/22 – Alloy Steel to suit high temperature and pressure industrial application.
For High Pressure & Temperature application Stellited F6 Face Seat & Disc available. Forged Steel Globe Valve available in Threaded End (BSP / NPT Female), Socket Weld End, Butt Weld End, Weld Neck End.
Testing Pressure
TESTING | HYDRAULIC | PNEUMATIC |
---|---|---|
800#, 1500# | ||
BODY | 3000 PSIG 5560 PSIG | - |
BACK SEAT | 2200 PSIG 4080 PSIG | - |
SEAT | 2200 PSIG 4080 PSIG | 80 PSIG |
